·Knob operation, easy to use
·A wide range of sponge test tube racks are available
·Prevents sample splashing
·The operation panel is simple
The multi-tube vortexer adopts DC brushless motor and microcomputer control technology. The unique knob operation mode is simple and easy to use. By replacing different test tube fixing sponges, it is possible to mix and culture various common test tubes. Up to 50 samples can be mixed and processed at one time. It is suitable for fields such as biotechnology, microbiology, and medical analysis.
·The timing time can be set arbitrarily within the range of 1 min~ 99 h 50 min, and the prompt sound will be issued automatically after the operation is completed
·Soft start, uniform acceleration, prevents sample splashing
·DC brushless motor drive, precise speed, long life, maintenance-free
·A maximum of 50 samples can be processed at a time, making the experiment efficient and fast
·The operation panel is simple, the microprocessor is precisely controlled, and the LED displays the speed and time in real-time
·Humanized program design, built-in 3 operation modes of timing/continuous/jog
| Model | DMTV-200S | ||
| Ambient Temperature | 0°C ~ 50°C | ||
| Relative Humidity | ≤70% | ||
| Power | AC100 ~ 240V 50/60Hz | ||
| Mode | Pulse/jog/timing/continuous | ||
| Rotating Speed | 100 ~ 2500rpm | ||
| Amplitude | 4mm horizontal rotation | ||
| Time Setting | 1min ~ 99h59min | ||
| Max. Load | 4.5kgs | ||
| Input Power | 70W | ||
| Dimensions | 410mmx275mmx435mm(LxWxH) | ||
| Sample Size | Test Tube Rack Model | Test Tube Rack Specifications | Applicable test tube specification (outer diameter mm) |
| DT200-T9 | 50 x Φ9mm | Φ9 ~ Φ13mm | |
| DT200-T14 | 50 x Φ14mm | Φ14 ~ Φ17mm | |
| DT200-T18 | 50 x Φ18mm | Φ18 ~ Φ21mm | |
| DT200-T22 | 15 x Φ22mm | Φ22 ~ Φ25mm | |
| DT200-T26 | 15 x Φ26mm | Φ26 ~ Φ32mm | |
| Weight | 20kgs | ||
